• Process control-based static and dynamic weighing applications
  • Capable of powering up to eight 350-ohm load cells
  • Comes with a 35-mm DIN rail mounting bracket
  • Features a 0.5-inch-high, six-digit, transflective LCD display with up to seven different colors and is viewable in all lighting levels from direct light to total darkness
  • Variety of mounting options and ColorZONE control options make it ideal for quick visual verification of weight status
  • Offers sample rates of up to 200 samples/second
  • Standard communication protocols include serial interface RS232/RS485, mini USB-B, Analog (0-10V or 4-20mA), Ethernet TCP/IP, EIP, and Modbus TCP, making it easy to connect to a PC, PLC, and other smart devices
  • Four programmable digital inputs and outputs are included to make it even more flexible
  • Setup and calibration of the model 201 weight controller is fast and easy using both the on-screen indicator menu prompts or Web browser interface via IP address
  • Both NTEP and Measurement Canada certified for legal-for-trade applications and is UL listed and CE certified
